EPS Fish Box Machine,EPS Fruit Box Machine Factory, Suppliers, Manufacturers

EPS Fish Box Machine,EPS Fruit Box Machine

EPS Fish Box Machine,EPS Fruit Box Machine Make eps foam beads to become EPS fish box or fruit box through steam heating and wind cooling.

Warranty:1 year

After-sales Service Provided:Field installation, commissioning and training, Online support

Place of Origin:Hebei, China

Voltage:380V

Dimension(L*W*H):3600*2000*2750-9500*2150*2950 mm

Applicable Industries:Manufacturing Plant

Key Selling Points:Long Service Life

Application:EPS blocks for wall insulation

Automatic:yes

Raw material:EPS raw material

HS code:84775900

control system:PLC With English Touch Screen

block size:according to requirement

machine color:according to requirement

material feeding:common feeding, pressurized feeding

System:vacuum system

Power(W):7KW

Weight:5000KG

With PLC English touch screen to realize full automatic production for feeding, heating,wind cooling, mould opening, mould closing and ejecting the foam box and different shapes.

1. Imported touch screen, full English display,graphical interfaces intelligent control, achieve man-machine conversation.Euro Tech Polystyrene Fish Fruit Packaging Thermocol Box Machine

2.It can carry out full automatic and semi-automatic.Euro Tech Polystyrene Fish Fruit Packaging Thermocol Box Machine

3.Taiwan AIRTCA hydraulic system is stable run, low noise, high clamping force.

4.Vacuum system accelerates product shaping speed, shorts the cooling time, reduce product water content.

5.Optimized design is clear and easy with high intensity and high performance-price rate.

6.This machine can carry out heating, cooling, feeding and ingot stripping process to adapt to different EPS products.

7.Perfect malfunction checkout system and motor protecting system which guarantees safe running of equipment.

Specifications of Standard EPS Fish Box Machine,EPS Fruit Box Machine:

1. Machine back plate and fixed mould plate are further enhanced. Machine plate and legs are made in a whole, largely increasing machine strength.

2. Machine plates are processed with zinc treatment to longer the use life.

3. Tie bar has self lubricating.

4. Machine hydraulic system adopt high-speed and high-pressure design, common machine mould closing speed is 180mm/s, E type machine closing speed can reach up to 250mm/s.

5. Mould locking is done at double sides to avoid steam leaking.

6. Ejection cylinder and mould opening cylinder can work simultaneously, reducing ejection time.

7. Use balance valve to control main pipe steam pressure and pressure sensor control mould pressure.

8. Use 4” to 6” big drainage pipe for fast draining. With spray device on the top of vacuum tank to ensure high efficient vacuum and decrease water content in the products.


Item	SPZ120B	SPZ140B	SPZ175B	SPZ180B	SPZ200B
mould size	1200×1000mm	1400×1200mm	1750×1450mm	1800×1600mm	2040×1800mm
product size	1000×900 ×330mm	1200×1000 ×330mm	1550×1200 ×330mm	1610×1400 ×330mm	1850×1600 ×330mm
back-window size	1100×940mm	1300×1080mm	1600×1250mm	1680×1440mm	1920×1640mm
mould opening distance	210-1360mm	270-1420mm	270-1420 mm	220-1370 mm	290-1290 mm
steam inlet	DN80	DN80	DN80	DN100	DN125
steam consumption	for making 1 ton of raw material it needs 12-15 tons of steam
cooling water inlet	DN80	DN80	DN80	DN80	DN80
cooling water consumption	45-138kg/cycle	50-150kg/cycle	60-190kg/cycle	80-200kg/cycle	90-210kg/cycle
compressed air inlet	DN65	DN65	DN65	DN65	DN65
compressed air consumption	1.5m3/cycle	1.8m3/cycle	2m3/cycle	2.2m3/cycle	2.5m3/cycle
inspiratory capacity for vacuum pump	185m3/h	230m3/h	280m3/h	280m3/h	280m3/h
installed power	11Kw	14.5Kw	16.5Kw	16.5Kw	20.5Kw
dimension	5020x1980x3200mm	4960x2140x3400mm	5000x2450x3500mm	5100x2610x3800mm	5100x2900x4080mm
weight	4500kg	5000kg	6200kg	6500kg	7000kg
time per cycle	60-100s	60-150s	100-180s	120-190s

FISH BOX MACHINE
